Universal 24V 11.8Ah 7S4P XT30 JST-2P Electric Scooter Battery

New 24V 11.8Ah scooter battery, universal.

The battery is designed for all types of electric scooters.

The battery capacity has been measured at over 11.8Ah when discharged to 21V. The battery has 4 mounting points.

Technical specifications:

• capacity: 11.8Ah (measured)
• nominal voltage: 24V
• minimum and maximum voltages: 21–29.4V
• maximum motor power: 500W
• Maximum charger current: 8 A
• Batteries used: 28 new 18650 cells, 7S4P
• charging socket: XT30
• Main power plug: XT30
• Protection: BMS up to 25A
• mounting hole spacing and size: 32 cm and 4.5 cm, 5 mm diameter
• Dimensions: 335 x 70 x 45 mm (length excluding mounting holes: 315 mm)
• Battery weight including base: 1.5 kg
• The casing is made of durable plastic

The set includes:

• the battery
